Specifications:

• Used for: Step brushless motor( square flange)
• Structure: Planetary gearbox
• Rated Power: /
• Radial load: less than or equal to 35N
• Radial gap: less than or equal to 0.04mm
• Planetary reducer length: 27mm
• Output Torque: Rated allowable load1N.M, instantly allowed to load 2.5N.M.
• Output Speed: variable speed as different gear ratio
• Output bearing form: ball bearing
• Model Number: PLANET GEARBOX36XG3.17
• Input Speed: /
• Inner ring gear material: steel teeth
• Gearing Arrangement: Planetary
• Gear ratio: 3.71:1
• Axial load: less than or equal to 8N
• Axial clearance: less than or equal to 0.02mm
