Specifications:

• working voltage: DC9-35V
• work temperature: -10 to 55 degree
• Type: Smoke Detector
• standby current: 4ma(relay NO) 13mA(relay NC)
• standard: EN54-7/UL268
• Model Number: SFL-823
• dimension: 100*46mm D*H
• contact rating: 0.5A DC28V
• Brand Name: SAIFULI
• Alarm output: relay output
• alarm indication: RED led on
• alarm current: 19mA(relay NO) 9mA(relay NC)
